Gryphon Gear: Rare Beasts of the Track (SEEKING DESIGNER TO COLLAB)

Ok that’ll be my mission this week. It always bothered me that my esc settings were appropriate but the idiot proofing didn’t extend to wild applications of throttle without just cutting the whole thing out. I want to create a seamless experience.

EDIT: First attempt. Kept the turbo section in the engine.jbeam file. Created new references in the electronics.jbeam file. Did diddlysquat as the “mainengine” reference in the engine file overrode everything so it all defaulted to that section and so I only had one turbo setting.

Second attempt: deleted the turbo section of the engine.jbeam file. Put separate entries for turbochargers in the electronics.jbeam file nested into each ESC mode. Now I have no turbocharger as there is nothing occupying the turbo slot in the engine file.

I guess I don’t really understand how this part:

"mainEngine": { //turbocharger name "turbocharger":"turbocharger", //Just tells the engine to look for the turbocharger section of this name

works but I’m not entirely certain that fixing this path will still lead to the files parsing correctly as I don’t know how I would create a file that has all of that in it. I can’t see any mention of a relevant command in the wiki, either.

Maybe I’ll ask on the beam forums.

4 Likes

While we’re talking about .car files, is there a way to modify the engine note, specifically to make it more raspy? I would make a thread, but doubt I could find much help.

You can change the sound bank of the turbo and supercharger effects as Beam has some pre-specified ones, but the whole sound conversion issue on export is a completely different beast… just ask Daffy it’s been grinding his gears for years :joy:

3 Likes

Damn… thanks for the info tho :slight_smile:

*Cries in M4 replica

Now that the She-Devil has been sold (for about twice as much as I expected), I can make this final post which rehashes all the content in one place, and that will finally be it for this model, and on to the next because I could milk it more with art and shit I think it’s more than time to move on because it’s hard to keep with the cool kids if you just do the same thing over and over again. Also I need to stop drawing the succubus giantess.


The original temptress, the irresistible demoness. Can you quench the fires of her lust, or will your soul be consumed like all before you?

only blocked in 246 countries lol

This video link will actually work

Following a highly successful year for their motorsport division, Team Ninja Horse (in particular their partnership with Znopresk Automobil to dominate the AMWEC), Gryphon Gear merged with fellow small performance outfits Dark Shine Designs and a large portion of Soltra in 2016. Thus they were able to expand the scale and the scope of their operations. But this was a big gamble, as it depended on them being able to capture a share of a highly competitive market quite different to their usual ultra-niche investors. The challenge was to stay true to their ultra-performance roots, while making something new, and something more accessible, for turnover an order of magnitude higher than any of their other projects.

Prior to this, they had flirted with the idea of having a crack at the “slightly more reasonably priced” supercar as opposed to their private race cars and ludicrous hypercars, but beyond a number of limited run projects with larger manufacturers, they lacked the capital to go it alone. But with the booming interest in high performance going unabated, 2017 was to be their time. The proposed price would be around 350k, and, in line with their competitors, the aim was to produce between 350-400 units. Single trim, you get what you get and if you want extra it’d be up for negotiation.

Lilith was the first GG factory car that was truly built to be lived with more than flung around by a professional race driver. Nonetheless it retained the GG philosophy in every aspect of being lighter and sharper and doing everything for the sake of speed, including the integrated torque distribution system in development since the Mercury project, and 4 way active aero, but eschewing the active spring suspension, surround sound systems and luxury seats common to its competitors. It was firmly pegged on the more committed end of the spectrum, yet hundreds of hours were spent ensuring that the ride had road manners as well as visceral racing feel. The V8 may have felt a relatively “pedestrian” choice to some but the 10000rpm redline was anything but. Boosted by GG’s “go fastest” reputation, the pre-order list filled up faster again. And once cars were delivered, interest surged yet again once it became clear that the quest to create something that lived up to its iconography had been a success: Lilith was far more potent than a regular mortal could handle yet far too tempting not to try. Evidence of its appeal came with the record sale of a model with the unique “She Devil” livery with factory decals, the face of their marketing campaign, for an astronomical 2.665M.

This placed GG in a strong, yet also delicate position. Their fanbase was created off a defiant celebration of the ICE. Their motorsport activities heavily leaned on the same. Yet within the space of a decade they had gone from brute force and a sledgehammer to embracing finesse and innovations of the future. Such wisdom indicated the decline of the ICE was upon them, and they had cannily responded by making Lilith a truly economical performance machine (at 6.2L/100km!), but even this would soon not be enough. A time would come when they would have to make the commitment to switch energy sources, making this even more so one of the last hurrahs for the screaming, flame spitting octane burning engines of yore.


Fact Sheet

Overview

Manufacturer Gryphon Gear
Production 2017-present
Assembly Donnybrook, Victoria, Australia
Designer Stroppy McHorseguy

Body and chassis

Class Sports car
Body Style 2-door coupé
Layout Rear mid-engine, rear-wheel drive
Platform Carbon-aluminium composite monocoque
Doors Dihedral

Powertrain

Engine 4400cc VVT-L bi-turbo V8
Power 810bhp @ 9000rpm
Transmission 7 speed DCT w/ E-LSD

Dimensions

Wheelbase 2.34m
Length 3.96m
Width 2.01m
Height 1.10m
Weight (dry) 1254kg

Performance on factory Trofeo tyres

Top speed 368km/h
0-100km/h 2.50s
1/4 mile 9.43s
1km 16.86s
20m skidpan 1.29g
250m skidpan 1.42g

Someone pointed out that the succubus must have been like nearly seven foot tall. Well, I’m going to own that and say yeah sure, the company hired a seven foot tall model for the photo shoot lol. Bite me.

30 Likes

Still waiting on that jbeam tweaking guide ;-;

It’s worth noting that I never wrote a .jbeam tweaking guide because I’m still learning a lot of things about how to adjust .jbeam files. And also I’ve been too busy at work, which you won’t notice because all that means is that I make an average of 2 good cars a year.

But as of late, secret’s out, I’m remaking another GG car.


2015 Mercury

Back in, well, 2015, when the game was still in Kee engine, I thought I’d finally give my hand at properly flogging the one mid-engined body the game had at the time, which meant +15 tech spam everywhere, a stupid big engine that needed its own oil refinery, and enough fixtures to crash the game every time you clicked on the car. This was also back in the day when 8 cylinders was the most we had. The ensuing result was… well I’ll quote myself.

As if I didn’t spend most of this company thread making shit like that anyway. But Mercury was special because I wanted it to be the first car to break a number of benchmarks in the game at the time, including a 2hp:1kg ratio.

Later on, I decided I’d see if I can make it “street legal” and send it to 500km/h.

Suffice to say the design was awkward because I was trying to force the body to do things it really didn’t want to do. I was also forcing the engineering to do things the game didn’t want me to do so that Mercury ended up horribly unreliable and undriveable so I always wrote it into the lore that, well, the technical achievements were a Pyrrhic victory at best.

Fast forward 4 years and the game’s changed a lot. So I figured I’d take another look at the car. Turns out that the only body which actually suits my original aims is the same, only now the morphs behave differently and the seams are horrible and indelible which makes it hard for someone like me to work.

Anyway, as is customary I’ve reached about halfway through the first draft so have some mock-ups. The colours are as always only chosen so I can see what I’m doing, but who knows what it’ll be when I finish.

I can’t design the headlights for shit, FML

God damn changing the shape of the windows and roof-line is torture on this body

so tempted to just give this Regera tail lights and be done with it

Something’s just not sitting right with me, so as usual I guess one could expect some pretty drastic changes down the line. What won’t change is that it will have over 2000hp and hit 500km/h fair dinkum and pack a shit ton of downforce so it’ll corner like the clappers too.


edit: here’s an idea… not sure if I’ll keep it…

28 Likes

Impressive stuff, making that body look low enough to not be ridiculous. Good colour combo, and man. That door. Keep it up :wink:

butts

I could really do with some help with the colour scheme actually. Suggestions?

More progress to follow when I work out how to do the headlights and also finish the side panels.

Also could I ask the creator of the nega tape mod a massive favour and suggest that they redo the mesh of their fixtures to make it an even grid instead of radial vertices? Coz they’re fantastic for masking but they also stamp absolutely horrendously because I imagine they were only intended for use to make things blank, but other options make a huge difference.

32 Likes

I remember when I was back in 9th grade, during the survival swimming portion of gym class, I scrolled through this photo on my phone. I remember thinking to myself, “holy bejesus what the fuck” (in the kindest way!)

Please do something that’s as garish as this lime green.
Maybe like a Mazda Polymetal Grey with green accenting.

16 Likes

I think that dark blue with gold accents might work quite well, I’ve also done a lighter, icy blue with white highlights. Bright blue and lime green for my electric stuff. Yellow and black (carbon maybe) always looks good, just depends how messy it’s going to get to cover things up. I’m really liking it so far though.

So, uh, I got distracted by CSR116 and ended up farting around with Kelpie in Beam…

21 Likes

I am now very close to declaring the remake of the 2015 Mercury complete (at least in Automation). So here it is in a colour close to the original eye-searing lemon-lime of the Kee version :joy:

First, the overall idea of the shape:

In more real-world lighting:

In which I unwittingly reveal that I am an ass man.

You’re probably thinking that rear window is a bit pointless and you’re mostly right. The rearward visibility in this thing’s gotta be a joke.

Many manly tears of frustration were shed in trying to reshape the A pillars into a panoramic window with a tapered roofline. The window-roof seam on this body is BRUTAL.

I do like that Chickenbiscuit’s lights glow in photo mode. I’m thinking I’ll make a fully cyberpunk trim but I just haven’t figured out the colours yet.

Okay last one for now.

I suppose that the next part is to go to town on .jbeam editing, during which Fite Me 3 will start happening, and then all that follows…

EDIT: here’s a video of a simple test, having fixed some things (and not others)

34 Likes

Considering the limitations of the 12C body, you have done an excellent job in remastering Mercury for UE4, right down to the exterior color, and added a few new styling features to boot. Well done!

So I may have mentioned to some people that with (a lot of) help (thanks to @ElMenduko for getting this ball rolling) I am trying to get the active aero working on the hypercars so that cars submitted for Fite Me 3 with active aero will… actually get something of the sort.

Right now however I have a bit of a technical issue. Beam doesn’t like making bodies that withstand stupid high forces such as what would be required to have a wing open at 450km/h and above.

The teal beam is the “hydro” that expands to lift the wing. However because I // several rows to leave that free, now the force is all concentrated on a “hinge” and this hinge, as you can see, is collapsing at high speeds which then causes the car to become very unstable.

Having already set the strength, spring and deform of the rear chassis to astronomical levels, I’ve spent like the last 3 hours on and off trying to find the appropriate geometry to fix this but all I seem to be doing is breaking the car and the simulation :joy:

So yeah it may be a bit more work getting this active aero up and running. I haven’t even started tuning the thing so that it’s actually functional.

EDIT: For reference, here’s the vanilla SBR with the active wing.

Closed, stationary:


Open partway at about 23m/s:


Airbrake deployed on hard braking:


It’s hard to see but the hydro beam is set between the sp3 and t4 nodes. For that matter the sp3 nodes are collision-less nodes whose sole purpose is to serve as the anchor point for the hydros. Looking at the rear wing file, it’s clear there’s a significant amount of reinforcement in addition to the frame, so I may try to emulate this too.

EDIT 2:

Well, I copied the SBR idea but clearly I’ve messed something up as the mesh is all kinds of turbofucked… but hey, now the car behaviour is as stable as it was before again (see the speed indicator)!

EDIT 3: worked out the problem, I placed the hydro anchor nodes in the group that goes with the car body and that has selfCollision and collision set to true by default, and kept overriding my own settings until I altered the argument of each node to take them out of the group as in:

//wing hydro anchor points
{"nodeWeight":0.5},
["HydroAnchorRL", 0.362788, 2.09, 1.48 { "group":"No_Group", "collision":false, "selfCollision":false }],
["HydroAnchorRR", -0.362788, 2.09, 1.48 { "group":"No_Group", "collision":false, "selfCollision":false }],

But the wing now collapses as usual at speed even with beamspring values of 2 million so time to go build a cage to try and steady it out…

11 Likes

I have to admire your dedication. Just looks to damn hard for mortals to mess with.

Alright, some progress! With the help of @TrackpadUser the collapsing beam problem has been sorted out. With that I learnt how to adjust the beams up front too.

Wing beams marked in Red

A bit hard to see here but reinforcement beams in yellow, and Hydro beams in cyan

With some study of how .lua and the electrics Streams work, I’ve managed to make some kind of active aero with independent front and rear flaps function more or less.

In the case of Mercury I had to actually test the behaviour of the car quite a bit as the relationship between traction and downforce changes markedly at around 240km/h, then at 320km/h, and especially between 400-450km/h where tyre traction in general goes extremely wonky…

A draft bit of logical arguments… my math and coding isn’t good enough to map out a set of values automatically so manual adjustments it is

In short, at 2130hp unless I mitigate how much front aero robs downforce from the rear, prodding the throttle will result in a spin at almost any speed, so I made it such that the further you depress the the throttle, the less the front wing activates. Right now though, this is causing problems if the car dips below 400km/h off throttle as suddenly the front wing goes from “closed” to “quite a bit open” and the car spins. I’ll have to work it out. Maybe I’ll slow the front hydros down, that will probably help a fair bit.

The only two things I haven’t worked out are:

  1. How to add my custom inputmap DRS button into the mix
  2. How to read the floating inputsteering value such that I can make the DRS cancel itself if the steering wheel is turned more than a few degrees (the wisdom of which I am debating, since this may in itself cause the car to suddenly destabilise). On that note if I work out inputsteering, then I can work out how to get 4 way aero working, which would be well wicked!

Work gradually continues.

EDIT:

because I’m one of the furthest things from an engineer you could get a physician with a humanities bent I stupidly forgot that the entire purpose of having .lua script is so you can put math in it.

So to smooth out the operation of the wing and make it truly adaptive, since this car’s stupid 2130hp means the behaviour is highly dependent on throttle input at varying speeds. Which means that what I should be doing is modelling the front wing angle as a function of the throttle.

Obviously this:

isn’t going to be it, but I’ve verified that it works

look how it accelerates like a bad motherfucker lmao

EDIT 2: the steering input works!


So in short, electrics.values.steering measures the steering angle. I’m not certain that this is in degrees of lock and I’m still too much of a noob at Beam’s UI to check this value in the console (anyone tell me how to do this I’d appreciate it). math.abs is the absolute value, as steering left produces a positive value, and right a negative one.

This is exactly what I want to know when, in future, I’ll be working on 4 way independent aero. This means things like the Mitsubishi HSR, or the Pagani Huayra, or even the SRT Tomahawk X (for that I’ll need some mad slidenodes), or even the Zenvo TSR-S’s silly pivot wing (for this I’ll need perfect placement of the hydros).

For this first project though, all I want is for the steering angle and the throttle to affect the front wing. I’ve decided the rear wing angle will remain fixed except when DRS is activated. Under most conditions, this car really needs all the rear downforce it can get. The front wing however, is such that the wing should exert more downforce with more steering lock (to an extent), and less if the throttle is depressed. This is because the car has more than enough power to power oversteer at almost any speed (all the way up to 500km/h).

But with the wing being what it is, above 400km/h if it is up at the maximum angle below stall angle (about 15 degrees), then it will also have a tendency to oversteer. Furthermore the rear wheels lose quite a bit of grip at these speeds, making keeping it stable under acceleration harder.

To combat this, I need something like this:

Where the x-axis is speed in km/h, the y-axis is wing angle in degrees, the red line is the maximum angle of the wing and the blue line is the minimum (except when DRS conditions are met and the toggle is pressed such that values.electrics.DRS = 1 or something).

To this end a suggestion from @ramthecowy later, and I might have something like this:

Where that e-x function may turn out to be something like this:


because electrics.values.wheelspeed is measured in m/s.

More testing to follow this week.

28 Likes

Ok enough editing one post. Here’s the next step of progress:

  • So that lovely exponential power formula didn’t work out because Beam took one sniff of using a floating value as an exponent and told me to fuck off lmao. So I had to use something a bit more discrete. Sad. EDIT: HA I got it to work!

  • Rear wing currently just set to maximum effective angle above 80km/h when not braking. I am considering changing this to be more dynamic such that when not accelerating the wing is slightly lower. I don’t know whether I’ll change it for steering angle yet.

  • Front wing is quite dynamic but I need to build in a gradated throttle deadzone to reflect that the car requires more power to maintain a static velocity.

  • And of course, the DRS logic, which scares me right now so I haven’t tried it yet and probably won’t until like, Friday.


Okay I think I’m happy with this bit of logic for the front wing.

I didn’t show the full program or the other local values but you can probably extrapolate well enough. I think I will reduce the angle on the rear wing just slightly and only when the throttle is lifted off and the steering is relatively straight, just to reduce drag. So the calculations for its effect will be fairly simple.

But DRS will reduce the wing angles and shut the front wing for the purpose of absolute maximum acceleration. My mission will be to find out the minimum angle at which DRS can be activated and full throttle used without lighting the rear wheels up, which it definitely will haha. I may have to use an actual polynomial curve just to get over the stupid 400-450km/h traction loss.

20 Likes

How To Create Active Aero

an attempt at documentation

With thanks to @ElMenduko and @TrackpadUser for their help getting the process started

Now that I’ve figured out Mercury, more or less, I’ll see if I can take you through the process of making active aero from start to finish, because I have to start from scratch anyway due to some changes in my mesh and fixture designations.

1. Exporting and Unpacking

We start with the export, of course.

To make active aero work you should consider first the relationship between the wing angles in Automation and Beam. If you want your wing to be effect neutral when it is shut, make sure you set the Automation slider to 0. This is by far the easiest way as to fix it later requires cumbersome .jbeam edits that have no guarantee of working

This appears to have some superfluous bits! Wonder what I’m going to be doing with those…

Now to make editing faster so I can just open in Beam and reload the model with Ctrl + R, I’ll unpack the mod and put it in a folder named unpacked



2. Tidying up the Node labels so you can see what the hell you’re doing

Before you start this section, you should probably familiarise yourself with JBeams, Nodes, and Beams.

Now we load the mod in Beam, open the Debug menu, visualise the beams and nods and importantly, the node names.

Suffice to say it looks like a right mess right now. But it’s important to know which nodes are what as we’ll be doing a LOT of changing.

Okay let’s focus on the rear wing. I’ve now ascertained that the fixture is named EFixtureType::EFT_WING56

It shows up in the car’s .jbeam file as such:


That’s one hell of a mouthful. Let’s rename it RWang by finding and replacing every mention of it. The left part is the automation export designation. Don’t fiddle with that or the fixture will vanish. The stuff in [parentheses] is what you want to rename.

But note! that I did it such that I also renamed all the nodes in one fell swoop, because the nodes are what I need to rename, like so:



Much better.

3. Optimising the geometry and reinforcement of the wang wing

You will note there are 8 nodes in a box, and this comprises the frame of the wing. But a box isn’t exactly the sturdiest structure at high speed when there’s a lot of downforce on it. And I want to attach hydraulic beams to the back, so that has to be sturdy. So instead I am going to make it a wedge by deleting nodes RWang4 and RWang5


Now they are commented out I better also comment out all the beams they are supposed to anchor.


And while I’m at it I also highlighted the beams so I can visualise what I’m doing better. Red is the wing itself, yellow are all the beams that support the wing.

As you can see the supports for the wing are arranged around the mesh because that’s how it exports.

But this is a ticket to the mesh collapsing at speed, especially when I start removing supports because what I want to do next is to actually create a hinge by having the wing attached at only two points. Which means removing the beams that connect to RWang2, RWang3, RWang7 & RWang8.


Now it can swing around freely! (It would rather, if the fixtures I used to create a “mount” for it were set to collision = false, but they’re not for now).

As I said before, there is no reinforcement for the wing hinge. It needs some. We should attach it to the “subframe” of the car for maximum rigidity without actually messing up the mesh with too much tension. So I attached it to the nodes that actually frame the engine: rx1 and rx2 as well as body mesh nodes a2

At this point definitely reload your car again to make sure the physics don’t instantly wig out due to some beams snapping at the speed of light or something.

4. Installing the Hydraulics

Hydraulic beams are called hydros in Beam. You can read up on them here.

In short, a typical hydro .jbeam code will look like this:

  • Ignore the highlight bit, that’s just me colouring this cyan so you can see it when I’m done
  • beamPrecompression is the length the beam will immediately try to emulate on spawn. I have not yet been able to think of a reason to leave this at anything other than 1. If you want to play around with the other properties you should look them up first.
  • The bottom two lines are the important bit. They’re the hydro beams themselves. The first two parameters are the nodes which the beam is attached to. The beams, therefore, look like this:

  • "inputSource": is the key to everything. I shall explain that in further detail later.
  • As for the rest of the ins and outs (literally), well, that should be pretty self-explanatory as it pertains to how much and how fast the beam extends and shortens. There’ll be an element of trial and error in that, because it will become quite clear that the wing’s effect on downforce depends on the Angle of Attack, which is affected by how extended this hydro is. And that is the absolute crux of translating an active wing into one that effectively modulates how your car handles, so let that sink in for a while.

Now that we have a wing that starts off shut, let’s just check the AoA in the aero debug section. Turn it on and set the car in motion:


Perfectly balanced as all things should be Good, this is what we want to see.

5. Checking the aero effect:

You’ll note that I put the hydros right down the bottom of the .jbeam. It doesn’t have to go there, but it sure makes things easier. At the very least they should go after all the nodes because you can’t have beams without nodes and Beam will get very confused if you screw the file up that badly.

But what else is down the bottom of the files? "Triangles".

At this point I suggest you look up “Collision Triangles” in Beam. In a nutshell, they are triangles defined by groups of 3 nodes. They form a surface, and this surface then has an effect on either drag, lift, or both, depending on the angle of incidence at which air strikes it (thus is the extremely simplistic Beam aero model, not that we need more than this currently).

Some of you are wondering why “wings” in an Automation export file are the only thing that exert downforce. That’s because they’re the only things currently that automatically generate “coltris”. You can check this for yourself at the bottom of the .jbeam. If the fixture doesn’t generate coltris, it’s not having an effect on lift. But the good news is, if a fixture has nodes, then you can create coltris yourself!

I’m going to be changing this entirely, in tune with the real top speed of the car among other things. But what’s really important here is the stallAngle. This is, quite simply, the stall angle of the coltri (you should look up stall angle). In a nutshell it’s the angle at which a surface stops affecting lift and drag sharply rises. For perfectly smooth surfaces it’s around 15 degrees, or just under 0.262 radians (the value I suggest you use for the stallAngle).

This will ensure that you then have a wing with predictable and somewhat realistic (within the bounds of the simulation) behaviour, and also reveals my goal of an active wing: make sure it creates enough effective downforce for whatever speed and throttle input it requires, but also allow it to extend enough that it creates significant drag to act as an air-brake under braking. All that will be borne through the .lua programming, which is… still further down the track.


Tune in tomorrow for the next part and I’ll show you how to map out the custom inputs and the .lua! Then I’ll show you what the bigger plan is for my extra fixtures uwu wats dis

Here’s a really important tip: you can move fixtures just like you can move nodes using x,y,z coordinates. x is the left-right axis, y is the front-back axis, and z is the bottom-top axis. If a fixture isn’t attaching right or scaling to your liking, if it isn’t automatically integrated into the mesh of the car you can alter it, which is exactly what I’ve done here. In short I’m going to animate these front flaps too, but they’re in a finnicky spot so I’ve deleted their coltris and I’m using a different hidden wing to generate the downforce, because I’m cheating lmao.

13 Likes

How To Create Active Aero (cont.)

here comes the really fun part

To this point you should now know how to manipulate the .jbeam in order to move and scale your fixtures, and to change the mesh to allow your structure to move the way you want them to. You should also know how to install hydro beams.

Between the last section and now I went back and changed the exported mesh a few times. Unfortunately I haven’t worked out how to re-export without having to make all of your .jbeam edits from scratch (very painful), so for now just be very very very sure you are not going to change any of your fixtures before you commit!

I’ve now updated all of the wings, supports and hydros.

You can see here that for the time being I consider the front two flaps to be too precariously positioned to actually take much downforce, so I’ve elected to keep my invisible wing hidden in the middle of the car as the one with collision triangles, and the front two flaps will operate, but they’re cosmetic.

So with that, onto the next part:

6a. Defining your Vehicle Specific Binding

If you do not want to add any kind of DRS or manual switch/control over your active aero and just leave the whole thing automated, you can ignore this step

A Vehicle Specific Binding is a control which manipulates something, well, specific to your vehicle. That is to say you can bind a control to something special that you’ve programmed to work for this entity alone. In this case, that’ll be the DRS button, as the intention is to make these flaps work such that while DRS is active, the drag is reduced to a minimum. Furthermore I want to be able to turn it on, and off, but also to have it turn off automatically or not turn on at all if a certain set of conditions is not met. For that, I will have to create a .lua file to program the part. That will come later.

For now, start by reading the BeamNG documentation on Vehicle Specific Bindings. It covers everything in enough detail.

So now that you’ve done that, you should then have a file called input_actions in the mod folder with all the .jbeam files:


(This file is called input_actions.json)

And in it all you really need is something like this:

{ "drs":{"order": 1, "onUp":"electrics.values.drs = 1-(electrics.values.drs or 0)", "title": "DRS", "desc": "Toggles DRS" } }

order: the order in which the commands come, which is useful if you have lists of commands for multiple various controller inputs. I’ve only got one command, so this is kind of superfluous

onUp: the command is triggered when the relevant button is lifted. Which in this case means you can press and hold it and it won’t trigger, but when you release the button it’ll trigger.

electrics.values.drs is a custom electrics input I’ve designated for this command. At this point you’re going to want to read up on Streams. In short, these are the values that reflect the state of a component or characteristic of the vehicle. That is to say that this is all of the data of what the vehicle is doing that Beam has, and that determines how it behaves and interacts with its environment. You can also manipulate this information or use it to manipulate other things, which is exactly what I plan to do later. As said before, electrics.values.drs is a custom value that will be manipulated by the .lua I will write.

The reason I’ve written the code the way it has been written above is because the same button turns ON and OFF (or between 0 and 1), but this one line covers both scenarios regardless of whether the state is ON or OFF. It’s especially important that I do it this way because the .lua program I’m going to use also has the power to switch DRS OFF (to 0), so I don’t want to confuse the system by having it try to turn the DRS OFF when the system already turned it OFF for me. This way, if I turn DRS ON and then my .lua script turns it OFF, if I hit the button again it’ll just try to turn it back ON.

Once you’ve done that you also need to create a file that sets a default binding for your Vehicle Specific Binding. This is so any user that uses your mod can then find that binding and change it to their liking.

So once you’ve made your input_actions.json file, just open Beam, and set your binding. It should turn up in this menu:


ta-daaaaaaaaaaah

Once you’ve set your input, a temp .diff file will be created in a different folder (read the documentation to find out where). You rename it .json and move it into this folder:


Like so:


c29b046d is Beam’s designation for my Logitech G27

Then, when you open the file again, the vehicle specific binding will appear briefly in the top-right corner of the screen:


Only the Keyboard binding appears here because I don’t have my G27 connected

6b. Programming your Wings

This is the most fun part, as it’s where you take all the parts you’ve crafted up to now, and you write a series of logical expressions and you get those parts to do things. In the scheme of things making some flaps move up and down is pretty simple but the advantage of working with simple systems is that you can achieve complex things with their behaviour.

To prime yourself for this, you should familiarise yourself with .lua unless you already know how to code.

First, take a look at your car.jbeam file. Near the top is a subsection called "controller"


Now, create a folder called lua (location shown below), and within it a subfolder called, you guessed it, controller


Here’s where you put your .lua files. Which should be named the same as what you specified in the .jbeam.


Make sure that you specify they are .lua files though, I once spent a good half an hour trying to figure out why my programming wasn’t doing anything before I realised I forgot to change the suffix!

At this point it’s probably a good idea to take a look at the file from the vanilla Beam car, the SBR, which you can find in Steam\steamapps\common\BeamNG.drive\content\vehicles (depending on your root tree). You can also examine the .lua files of other mods for ideas, as some of them do all kinds of things with functions that pull math from places I don’t understand, change your UI, fly planes, fire missiles… but for now, just look at the SBR’s file.

I honestly still don’t know what some of these lines do. I have no idea what M.type or M.relevantDevice means. What I can say is that this file is divided into a few sections. The first section is about defining various variables. When you get to the line local function init{} that is the line that initiates the code affecting behaviour. In this case it’s telling the spoiler to start at 0.

As you can see here, electrics.values.spoiler is actually a custom electrics stream. spoiler here is in fact the "inputSource" that you specified for the hydros, so make sure the names match up or it won’t input anything.

I’m not going to go into all the details of how the .lua logic works (some of it isn’t that intuitive but a lot of it is). If you can’t learn off this much you’ll probably struggle to make stuff of your own, and it’ll take me quite a long time to explain it all. If you want to see how I ruminated and struggled through it myself just look up a bit. Just know that you can pull values from the various streams and feed them into other streams, and that you can use math. And that for every if there should be a then and an end (elseif and else optional depending on how many conditions you want, but if there is more than 1 alternative condition you need to use an elseif, and the else is the final alternative condition).

The really important thing about .lua is that you can nest if/elseif/else conditions within other if/elseif/else conditions. This is what makes using multiple sets of logical operations possible: hence how it’s possible to make a DRS logic and an automated wing logic at the same time.

Document what you do using the --, this comments out the rest of your line in .lua. Otherwise you may forget what you were trying to do and since the code can get complex easily you can get lost.

7. Troubleshooting

This is the really annoying part. Chances are things are going to be really buggy. Chances are some beams are going to break, or you missed a tiny little detail. You’ll have to go over every step methodically to find where your error was. Common causes for things not working include:

  • Syntax errors (the entire mod will not work if there is even one syntax error)
  • “Beam reversal” where under force some beams flip around due to the geometry of the mesh or insufficient rigidity. This requires a lot of playing around with nodes, beams, nodeweights and beam spring. Just remember not to make the nodes too light for your mesh. The heavier the node, the more spring the beams it anchors will tolerate.
  • The mod loads but the wings don’t do anything: probably an input mismatch. Check that your controller slot is appropriately named, your controller files are .lua, and that your input sources match
  • The mod works and the hydros activate but the car’s handling sucks: you’re on your own. Work it out!

At the end of this all you might just end up having functional wings. It took me a few weeks to get this sorted from scratch and that’s only because I was absolutely determined to get this done. As for the result, well, you’re just gonna have to wait until the next Car Collectors Auction for a chance to get your hands on it, heh heh heh. If you don’t wanna wait that long, then learn how to do your own!

16 Likes
